120 Digital Multimeter

£30.00

The TPI Model 120 is a Compact, manual ranging, basic DCV 0.5% accuracy DMM.

In stock

SKU: 120 Category: Tags: , ,

Description

The TPI Model 120 is a Compact, manual ranging, basic DCV 0.5% accuracy DMM.

Usage Tip: When using the Model 120, press the DATA-H button at any time on any function or range to freeze the reading on the LCD display. This function is very useful when measuring in locations where the display is difficult to read.

The 120 comes complete with the following accessories:

  • 120 Instrument
  • Rubber Boot
  • Test Lead Set
  • Instruction Manual
  • 9V Battery

Features

Compact, manual ranging, basic DCV 0.5% accuracy DMM.

  • Safety: Meets CE and IEC 1010 requirements. UL Listed.
  • Large LCD: Easy to read at all angles and the majority of lighting levels.
  • Data Hold: Freeze readings on the display.
  • Rubber Boot: Added protection when the instrument is dropped. (120NB does not include boot.)
  • Versatile: Use accessories like a carbon monoxide attachment to expand the capabilities of the 120.2,000 count display
  • cULus 61010-1
  • CAT II – 1000V, CAT III – 600V
  • 0 to 600 volts AC and DC
  • 0 to 2,000 ohms
  • Audible continuity
  • 10 MOHM internal impedance
  • 0.5 % DCV basic accuracy

Specifications

 Model 120 Specifications
 DC Volts  Maximum Input: 600V (Minimum Input = 1.5V)

Maximum Resolution: 0.001V

Accuracy: +/-0.5%

 AC Volts  Maximum Input: 600V (Minimum Input = 1.7V)

Maximum Resolution: 0.1V

Accuracy: +/-0.8%

 DC Amps  N/A
 AC Amps  N/A
 Resistance (Ohms)  Maximum Input: 2KΩ

Maximum Resolution: 0.001Ω

Accuracy: +/-0.5%

 Frequency  N/A
 Capacitance  N/A
 Inductance  N/A
 Temperature

(K-Type Thermocouple)

 N/A
 Continuity  Audible at less than 100Ω
 Diode  N/A
 Duty Cycle  N/A
 True RMS Responding  No
 Conductance  No
 Pulse Width  No
 Data Hold  Yes
 Min/Max Record  No
 Time Stamp Logging  No
 Relative Mode  No
 Compare Mode  No
 RS-232 Output  No
 Process Loop Output  No
 Sleep Mode / Auto Off  No
 Protective Boot  Yes (standard)
 Display Type  2000 count LCD
 Range Selection  Manual
 Operating Temperature  32°F to 104°F (0°C to 40°C)
 Storage Temperature  14°F to 122°F (-10°C to 50°C)
 Humidity  80% non-condensing
 Size  6” x 3.1” x 1.2” (187mm x 86mm x 33mm) with boot
 Weight  12oz (340g) with boot
 Battery Type  9V Alkaline (NEDA 1604)
 Battery Life  500hrs Typical
 OverInput Category  CAT III 600V
 Agency Approval  IEC 61010-1
 Warranty  3 Years

Applications

Model 120 Applications

HVAC/R Applications:

  • Line voltage
  • Control circuit voltage
  • Heating element resistance (continuity)
  • Compressor winding resistance
  • Contactor and relay coil resistance
  • Continuity of wiring

Electrical Applications:

  • Measure line voltage
  • Continuity of circuit breakers
  • Voltage of direct drive DC motors

Tech Tips

Category Ratings:

  • Category I: Usually electronic equipment or equipment where measures have been taken to limit transient over voltages.
  • Category II: Single phase loads like appliance personal computers, television sets, and other household loads. Outlets located more than 30 feet froma CAT III source or more than 60 feet from a CAT IV source.
  • Category III: Distribution level fixed installations like distribution panel devices, short branch and feeder circuits, three phase loads, and single phase commercial lighting.
  • Category IV: Equipment and lines located on the power line side of a service panel or where a low voltage connection is made to utility power

FAQs

Frequently Asked Questions

1. Is there a way to measure higher current with a TPI DMM?

TPI DMMs (except the 120 and 126) have the capacity to read up to 10A AC/DC. Optional adapters are available for all models to increase the current range. Our shunt adapters are available to increase the range up to 1,000A AC/DC.

2. What other adapters are available for TPI DMMs?

Various adapters including carbon monoxide (A771), pressure (A620/630), and clamp-on low current (A254) are available. Contact TPI for additional information.

3. Which of the TPI DMMs will measure temperature?

All TPI DMMs can measure temperature by using the optional A301 K-Type thermocouple temperature adapter.

4. Which TPI DMMs can measure DC millivolts?

All TPI DMMs measure millivolts. Models are available with 1 or 0.1 millivolt resolution.

5. Which TPI DMMs can measure DC microamps?

The TPI 126, 133, 135, 153, 163, 183, 190, 194, 196, and 440 all have this capability.

6. Which TPI DMMs will measure capacitance?

The TPI 135, 183, 190, 192, 194, and 440 all have this capability.

7. What is continuity?

Continuity refers to a test performed on wires and circuits to see if a break(open) exhists. If the wire or circuit is continuous, the resistance reading will be at or near zero. The continuity range on a meter provides audible indication of a continuous circuit, allowing quicker tests without having to take your eyes off the circuit or wire under test.
