Wireless Air Velocity Vane Probe. Use with Your Smart Phone & FREE TPI View App to display air velocity, CFM, and temperature readings.

SP555 Wireless Air Velocity Vane Probe
SP555 Wireless Air Velocity Vane Probe
SP555 Wireless Air Velocity Vane Probe
SP555 Wireless Air Velocity Vane Probe
SP555 View Screenshot
SP555 View Screenshot
SP555 View Screenshot
SP555 View Screenshot
SP555 View Screenshot
SP555 View Screenshot
SP555 View Screenshot
SP555 View Screenshot
SP555 View Screenshot
SP555 Wireless Air Velocity Vane ProbeSP555 Wireless Air Velocity Vane ProbeSP555 Wireless Air Velocity Vane ProbeSP555 View ScreenshotSP555 View ScreenshotSP555 View ScreenshotSP555 View ScreenshotSP555 View ScreenshotSP555 View ScreenshotSP555 View ScreenshotSP555 View ScreenshotSP555 View Screenshot

The SP555 is a vane velocity Smart Probe. It measures air velocity and temperature; calculates CFM (Volume); connects to mobile device and uses the TPI View App. Perform average air velocity and air volume tests. 3 Year Limited Warranty

Features:

  • Measure air velocity and temperature simultaneously
  • Communicate with smartphone using Bluetooth LE and TPI View App
  • Record minimum, maximum & average readings
  • Multiple measuring units: m/s, km/h, ft/min, knots, mile/h
  • Automatically calculates and displays CFM through the View app

Applications:

  • Air velocity measurements in HVAC systems
  • Air duct analysis to balance commercial and residential HVAC systems
  • Fume hoods
  • Floor registers
  • Exhaust grills

£75.00
RRP exc. VAT

Where to Buy TPI Products

TPI View App
Use with DC710 and Select Smart Devices

Allows gas engineers using their smartphone to interact with TPI Smart Devices. Job Management allows you to create multiple JOBS and attach multiple REPORTS to each Job! Give each report a different reference/name; save to an existing JOB or create a NEW one! Learn More

SP555 Wireless Air Velocity Probe Specifications
Range98 fpm ~ 4900 fpm (0.5 m/s ~ 25 m/s)

-4°F ~ 140°F (-20°C ~ 60°C)
Resolution2 fpm (0.1 m/s) 0.1°F / 0.1°C
Air Velocity Accuracy± ( 2% of mv + 59 fpm)

± ( 2% of mv + 0.3 m/s)
Temperature Accuracy±1°F( 32°F ~ 113°F ) / ±2°F ( -4 °F ~ 31.9°F, 113.1°F ~ 140°F )

±0.5°C( 0°C ~ 45°C ) / ±1°C ( -20°C ~ -0.1°C, 45.1°C ~ 60°C )
+/-0.02 inH2O (0 to 1 inH2O) / +/-(1.5% + 20 digits) (> 1 inH2O)
Operation Temperature-4°F ~ 122°F (-20°C ~ 50°C)
Storage Temperature-4°F ~ 140°F (-20 °C ~ 60 °C)
Battery Life TimeAbout 30 hours
Battery TypeAAA x 3 (4.5V)
Weight3.74 oz (106 g)
