A251 AC Amp Current Probe Adapter
AC Clamp-on accessory for DMMs (0 to 400 Amps).
AC Clamp-on accessory for DMMs (0 to 400 Amps). Use this adapter with most TPI brand and any competitor DMM, clamp-on or oscilloscope having the capability of measuring up to 2000mV AC (2V AC), 10M Ohm input impedance, and equipped with industry standard spaced input jacks 19mm on center.
|Range||AC Amps: 0 to 400A|
DC Amps: N/A
|Accuracy||0 – 40A = ± 1% of reading|
0 – 400A = ± 1.5% of reading
|Output||1mA per 1A|
|Maximum Conductor Size||1.34” (34mm)|
|Lead Length||48” (1.2m)|
|Output Connection Type||Dual banana plug|
