265 Digital Clamp Meter

265 Digital Clamp Meter

£55.00

Perfect for tight, narrow, spaces. The TPI 265 with slim jaw and body is ideal for cramped work areas and crowded electrical panels.

In stock

SKU: 265 Category: Tags: , , , ,

Description

Perfect for tight, narrow, spaces. The TPI 265 with slim jaw and body is ideal for cramped work areas and crowded electrical panels.

The 265 is a hand-held, autoranging clamp-on DMM. Extra large numerals, capacitance, frequency and data hold are just a few of the features of the 265. An affordable choice, the 265 offers measurements in all basic electrical functions.

  • Slim jaw and body design for use is crowded electrical panels
  • Capacitance up to 4,000 micro-farads
  • Up to 400 AC amps with 0.01 resolution
  • Diode, resistance and audible continuity
  • CAT III 600V rated; cULus 61010
  • Test start and run capacitors
  • Measure heat anticipator current
  • Determine thermocouple voltage
  • Test line and control voltages
  • Measure heating element resistance
  • Measure and adjust variable frequency drives

Features

The 265 is a hand-held, autoranging clamp-on DMM. Extra large numerals, capacitance, frequency and data hold are just a few of the features of the 265. An affordable choice, the 265 offers measurements in all basic electrical functions.

The 265 comes complete with the following accessories:

• Carrying Pouch
• Test Lead Set
• Instruction Manual
• Battery

Specifications

 Model 265 Specifications
 Basic DC Accuracy:  0.5%
 DC Voltage (maximum):  600V
 Resolution (maximum):  0.1mV
 AC Voltage (maximum):  600V
 Resolution (maximum):  0.1mV
 AC Amps (maximum):  400A
 Resolution (maximum):  0.01A
 Resistance (maximum):  40MΩ
 Resolution (maximum):  0.1Ω
 Frequency (maximum):  400MHz
 Resolution (maximum):  0.001KHz
 Capacitance (maximum):  4,000μF
 Resolution (maximum):  0.001nF
 Diode:  Test Current Max 1.5mA
 Continuity:  Buzzer sounds at approx. 35Ω Response time; 50ms
 Overall Dimensions:  8” x 1.5” x 3.0” (203 x 38.1 x 76.2mm)
 Weight:  .6 lbs (272g)

Applications

Model 265 Applications

  • Test start and run capacitors
  • Measure heat anticipator current
  • Determine thermocouple voltage
  • Test line and control voltages
  • Measure heating element resistance
  • Measure and adjust variable frequency drives

Perform the following tests and/or measurements with the 265 and the appropriate function:

HVAC/R
DCmV • Thermocouples in furnaces.
ACA • Heat anticipator current in thermostats.
ACV • Line voltage.
ACV or DCV • Control circuit voltage.
OHMS • Compressor winding resistance.
OHMS • Continuity of wiring.
CAP • Motor start and run capacitors.
ACA • Motor and compressor start up current.
Hz • Frequency on controls and line voltage.

ELECTRICAL
ACV • Measure line voltage.
ACA • Measure line current.
OHMS • Continuity of circuit breakers.
DCV • Voltage of direct drive DC motors.
ACA • Start up current of motors, relays,  contactors and transformers

ELECTRONIC
ACV • Measure power supply voltage.
ACA • Measure power supply current.
OHMS • Continuity of circuit breakers and fuses.

FAQs

Frequently Asked Questions

1. How does the non-contact voltage feature of the TPI 270 and 275 benefit me?

The non-contact feature of the TPI 270 and 275 allows you to detect live circuits without using the test leads, which enables faster checks for the presence of voltage.

2. Which of the TPI clamp-on meters will measure temperature?

The 270 and 275 have this feature built in and the 255, 265, and 291 can measure temperature by using the optional A301 or a A312 K-type thermocouple adapters.

3. Which TPI clamp-ons can measure DC microamps?

The TPI 270 and 275 has the capability to measure DC microamps by using the test leads. This is very useful for making flame safety control current measurements. The 265 can measure DC microamps with the optional A213 adapter.

4. Does a clamp-on meter measure anything besides amps?

All TPI clamp-on meters measure AC/DC volts and resistance. Models are available with temperature, frequency, capacitance, and non-contact voltage detection capability as well as many other features. Various adapters including temperature (A301 or A312), carbon monoxide (A771), and pressure (A620/630) are available. Contact TPI for additional information.

5. Is it possible to measure AC amps on a device that uses a power cord?

Yes, to accomplish this you can use the TPI line splitter (A202). AC amps must be measured by isolating a single wire and the A202 line splitter does this without damaging the power cord.
