Description

Includes: 2 SP323s, 2 SP670s and A931 case. Use with free TPI View app!

SP323 Clamp Type Temperature Probe
Features:

• Temperature Range: -40 to +185 °F (-40 to +85 °C)
• Clamp Range: 1/4 inch to 1 1/2 inch (6mm to 38mm)
• Connect to Smart Device and use with the TPI View App
• Temperature measurement on air conditioning, heating, and refrigeration systems
• View “LIVE” Temperature Readings and instantly Save, e-mail and/or Print them
• Save, e-mail and/or Print “Differential” Temperature readings with one or two SP323 probes
• Perform, Save, e-mail and/or Print differential temperature readings such as Radiator Balancing or Flow & Return on Boilers or Heat Pumps
• Remote Data Logging Function with Multiple instruments logging at the same time
• Store ALL GPS tagged Test Results within the TPI View Job Management
• Use in conjunction with the SP670 high pressure smart probe to perform Superheat and Subcooling measurements

SP670 High Pressure Probe
Features:

• Pressure Range: -14.7 psi to 870 psi (-1 bar to 60 bar)
• Connection Type: 7/16″-20 UNF / ¼” SAE angled for connections in tight spaces
• Over pressure protected to 1000 psi
• Adjustable Schrader valve depressor for use on worn valves
• Replaceable Schrader valve depressor
• View “LIVE” High Pressure readings
• Save, e-mail and/or Print Pressure readings with GPS tagged Date & Time on Report
• Ideal for checking for compressor leaks
• Store ALL GPS tagged Test Results within the TPI View Job Management
• Use in conjunction with the SP323 temperature clamp smart probe to perform Superheat and Subcooling measurements
